TP-Link TL-POE160S PoE Injector Gigabit

NETWORK
Standards and Protocols : IEEE802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at

GENERAL
Certification : FCC, CE, RoHS
Environment : Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature : -40°C to 70°C (-40°F to 158°F)
Operating Humidity : 10% to 90%RH non-condensing
Storage Humidity : 5% to 90%RH non-condensing

PACKAGE CONTENTS
Package Contents :
- PoE+ Injector TL-POE160S
- Installation Guide
- Power Cord
- RJ45 Cable
- Wall Mounting Kits

HARDWARE FEATURES
Network Media :
- 10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m)
- EIA/TIA-568 100Ω STP (maximum 100 m)
- 100BASE-TX: UTP category 5, 5e cable (maximum 100 m)
- EIA/TIA-568 100Ω STP (maximum 100 m)
- 1000BASE-T: UTP category 5, 5e, 6 cable(maximum 100 m)

Ports :
- 1 10/100/1000Mbps RJ45 data-in port
- 1 10/100/1000Mbps RJ45 power+data-out port
- 1 AC socket

Power Consumption
Input : 100-240 V, 50/60 Hz
Output : Auto-determine the necessary power requirements (max. 30 W)

Basic Function :
- Auto-Sensing Algorithm enables providing power with 802.3af/at PD
- Auto-determine the necessary power requirements
- Wall-mounting and desktop installation supported
- Plug-and-Play

LED Indicator
- ON : Supplying power normally
- OFF: No power supply

Dimensions ( W x D x H ) : (125*59.4*36.8 mm)
